Silicone Addition Clear 35
++BLUE++ Crystal clear silicone, which are suitable for flexible infusion of LEDs and optical elements. These silicones are also very well suited for the simulation of water in aquariums and windows in the modeling. ++ENDBLUE++
description
Silicone A Crystal Clear 35 is a (platinum) addition-2-component casting silicone that cures at room temperature. The result is a crystal clear medium-hard rubber. The silicone is quite fluid and temperature resistant from -40 ° C to +200 ° C and is suitable for detailed fragile master models. This silicone is suitable for potting of electronic component and optical component and for transparent Forme without undercuts.
Technical specifications
|
The mixing ratio (by weight)
|
|
[A: B]
|
|
1: 1
|
|
Pot life at 23 ° C
|
|
[Min]
|
|
100
|
|
Ontmaltijd @ 23 ° C
|
|
[Hours]
|
|
20
|
|
Viscosity @ 23 ° C
|
|
[CST]
|
|
4000
|
|
color
|
|
|
|
crystal
|
|
hardness
|
|
[Shore A]
|
|
35
|
|
density
|
|
[G / cm3]
|
|
1.03
|
|
pull
|
|
[Kg / cm2]
|
|
30
|
Note: Pot life and demold time are temperature-dependent to a large extent. At higher temperature processing time and shorten demolding
processing
Silicone A Glasklar 35 can easily by hand or by machine mix. Mix the components A and B thoroughly in the ratio indicated (100: 100) .Verarbeiten the mixture within the pot life and wait by unmolding, until the whole thing is completely cured. The best properties are achieved only when to bake. Ask. The shape to 1 hour at 80 ° C in the oven
Further information
From air bubbles may be best after mixing by pulling the silicone vacuum immediately prevented. To bubbles, stir the A- and B-component well, but slowly, without preventing the storage in the air. You create the best a "figure 8" motion. If you want to reduce the Shore (stiffness), then you can add silicone oil from the store. If you do not want the silicone spatula to pour, but you can Silicone Thixo A (note: Silicone Thixo C !!) book. You can also add fumed silica. You can intense colors with silicon dye silicone.
The silicon reach their final properties after tempering / after-baking for 1 hour at 80 ° C
packaging
The standard package contains 1 kg, 2 kg, 9 Kg, 40 Kg or 200 Kg. For larger quantities please get in via the website contact us. Please make sure that you mix only materials with the same lot numbers
durability
When stored in closed packaging, cool and frost-free, the shelf life is at least 1 year.
safety
If the silicone often works during processing gloves and properly ventilate the area advised contribute. For safety information on the safety data sheet.
++DOWNLOADS++
| document type |
document name |
statement |
download |
| sheet |
DE - A data silicone crystal clear 35 Set |
product Description |
 |
++USP++
- Low shrinkage of <0.1%.
- highly liquid
- self-venting
- Suitable for grouting
- Refr. Index at 25 ° C 1.406
