NOTE: Since August 2023, polyurethane with a diisocyanate content of more than 0.1% may only be used in companies where employees have completed the required training.

Companies can register for an online training via THIS link.

You can also read more information here .

A two-component polyurethane (PU) casting system with an optional filler. This casting system is characterized by its quality, ease of use, and very high impact resistance, even when processed at room temperature. The system is ideal for small castings, mold fixation, foundry models, replicas, and prototypes.

• Beige colored two or three-piece system
• Designed for fast, high-precision castings with high impact strength
• Can be poured up to a layer thickness of 40 mm, provided you use sufficient filler
• Filler quantity varies depending on application and can even be omitted completely
• De-moldable after 10 hours (with a mixture of 1:1:3)
• Can be mixed with up to 600% (of total weight) of filler

Technical data

Without filler

Mixing ratio: A:B = 1:1
Processing time at 25°C: 5 minutes
De-moulding time at 25°C: 14 hours
Density: 1.08 g/cm³
Linear shrinkage: 0.2%
Maximum thickness per casting: 4-5 mm.
Glass temperature: 55°C
Hardness: Shore D 75
Tensile strength: 32 MPa
Stretch: 19%
Flexural strength: 48 MPa
Flexural modulus: 810 MPa
Impact resistance: 50 KJ/m²
Impact resistance after post-curing 8 hours at 80 ^o C: 150 KJ/m²

With filler

Mixing ratio: A:B:Filler = 1:1:3
Processing time at 25°C: 4 minutes
De-moulding time at 20°C: 10 hours
Density 1.6 g/cm³
Linear shrinkage: 0.2%
Maximum thickness per casting: 30-40 mm.
Glass temperature: 55°C
Hardness: Shore D 85

Processing

Add half of the desired filler to component A and the other half to component B. Now mix the filler thoroughly into the components. You can, of course, skip this previous step if you do not wish to use filler. Pour the components together and mix thoroughly again. Pour the mixed product into the mold at a steady rate, taking care not to entrap any air. Excessive heat buildup in castings thicker than 5 or 40 mm can be prevented by pouring multiple successive layers (allowing each layer to set before pouring the next). Wait until the indicated time has elapsed before demoulding. The thermal and mechanical properties will develop quickly, but it is possible to improve the thermal behavior by "post-baking" the casting for 8 hours at a temperature of 80°C. Do NOT use an oven in which you intend to prepare food later!

Important

The moisture absorbers in these products can settle, requiring remixing before use. This can be achieved by shaking the container vigorously before use. The less filler you add, the greater the heat generated during the casting and the less thickly you can pour at a time. Use a mixing bucket with a large surface area to maximize pot life.

Shelf life

The polyurethane casting system should be stored in a dry place between 6–28°C. The expiration date, which assumes storage within the specified conditions, is indicated on the packaging. Opened packages should be used as soon as possible to ensure product quality. The normal shelf life is 6 months.

Safety requirements

Caution: These are chemical products. Handle with care and follow the safety instructions below and on the safety data sheets.

Wear safety equipment such as impermeable gloves and goggles, and ensure adequate ventilation. Always keep out of reach of children and do not allow children to work with this product, even under supervision.

Further important safety information A component: NEUKADUR MultiCast 11

H-Code hazard statements

H302 Harmful if swallowed.

H319 Causes serious eye irritation.

H336 May cause drowsiness or dizziness.

P-Code precautions

P280 Protective gloves/protective clothing/eye protection/face protection
wear.

P264 Wash thoroughly after handling.

P305+P351+P338 IF IN EYES: Rinse cautiously with water for several minutes.
minutes; remove contact lenses, if possible; continue rinsing.

P337+P313 If eye irritation persists: Get medical advice/attention.

P405 Store locked up.

P501 Dispose of contents and container in accordance with local/regional/national/
international regulations.

Further important safety information B component: NEUKADUR Hardener ISO 1

H-Code hazard statements

H332 Harmful if inhaled.

H315 Causes skin irritation.

H319 Causes serious eye irritation.

H334 May cause allergy or asthma symptoms or breathing difficulties if inhaled.

H317 May cause an allergic skin reaction.

H351 Suspected of causing cancer.

H335 May cause respiratory irritation.

H373 May cause damage to organs through prolonged or repeated exposure.

H411 ​​Toxic to aquatic life with long lasting effects.

EUH204 Contains isocyanates. May cause an allergic reaction.

P-Code precautions

P260 Do not breathe dust/fume/gas/mist/vapours/spray.

P284 [In case of inadequate ventilation] wear respiratory protection.

P305+P351+P338 IF IN EYES: Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy to do. Continue rinsing.

P321 Specific treatment (see on this label).

P405 Store locked up.

P501 Dispose of contents and container in accordance with local/regional/national/
international regulations.

Documentation

EN - Product information Impact-resistant polyurethane D75.pdf

Multicast 11 original technical data sheet. pdf

Manual Casting with PU kit

Please contact us for the safety data sheets.
